Base Plate Asus 1700 TUF Gaming Z690-Plus Wifi

Asus 1700 TUF Gaming Z690-Plus Wifi Base Plate

ASUS TUF Gaming Z690-PLUS Wi-Fi takes all the essential elements of the latest Intel processors and combines them with ready-to-play and proven durability. With military grade components, an improved energy performance solution and a comprehensive cooling system, the base plate provides a stable performance and is a rock for marat games. It is &eactically, TUF GAMING Z690-PLUS Wi-Fi looks like the new TUF Gaming logo and incorporates simple ñ or geom é elements to reflect the reliability and stability that the TUF Gaming series defines.

PERFORMANCE S &O ' S LIKE A ROCA

With an improved power delivery and comprehensive cooling options to boost the Intel Core 12 ª processors, support for a memory and storage m &aecos r &aecatos pidos, the TUF GAMING Z690 base plates are the perfect base for your top n &uenderumo battle platform.

DISE Ñ OR ENERG &IateA

DrMOS

The built-in VRM features 14 + 1 DrMOS power stages that combine MOSFET and high-side, low-side controllers into a single package, providing the power and efficiency required by the 12.a generation Intel Core processors to provide stable performance for current and future Intel processors.

Dise ñ or six-layer PCB

The m &uantiples layers of PCB optimize the heat management for the c components, which provides space to boost the CPU m &aUtits of the stock speeds.

ProCool connectors

In comparison with traditional feed inputs, ASUS ProCool connectors are manufactured with strict specifications to ensure full contact with the power supply cables. The resulting low-level impedance helps prevent hot spots and connector failures.

TUF Components

Military-grade TUF chokes provide a power s &oclida to the CPU, which improves system stability. The patented capacitors provide up to 20% m temperature tolerance and a five-fold higher life.

Digi + VRM

The integrated digital voltage regulator (VRM) Digi + is one of the best in the industry, optimized for an ultra-smooth, ultra-clean power delivery to the CPU at all times.

COOLING

Extended VRM heat sink

The vast surface of the huge heat sink covers VRM and chokes to improve heat dissipation.

Extended PCH heat sink

An expanded surface area for the chipset sink maximizes performance and heat dissipation.

Three M. 2 slots with heat sinks

Three out of four M. 2 slots have dedicated heat sinks, which maintains the M. 2 SSDs at the latest operating temperatures to ensure constant performance and reliability.

Full fan controls

The TUF GAMING Z690 base plates feature full fan controls that can be configured to bring either the Fan Xpert 4 utility or the awardee ASUS UEFI BIOS.

MEMORY AND STORAGE

DDR5 overclocking force

TUF GAMING Z690-PLUS motherboards improve DDR5 performance by providing overclocking options not only for high speed kits, but also entry level memory modules that have a locked power management IC (PMIC).

Four PCIe 4.0 M. 2 slots

The four PCIe 4.0 M. 2 slots support up to two 22110 devices and also provide NVMe SSD RAID support for a potential performance potential. You create a RAID configuration with up to four PCIe 4.0 storage devices to enjoy the data transfer rates m &aaltios r ádas.

CONNECTIVITY

PCIe 5.0

The 12 ª Intel processors bring the PCIe 5.0 compatibility to the market. PCIe 5.0 offers twice as much data transfer speed as PCIe 4.0, making it robust enough to handle new tasks with large amounts of data. PCIe 5.0 also provides other benefits, such as changes in the ctrics to improve the integrity of the ñ al, CEM connectors that are compatible with earlier versions for complementary cards, and compatibility with earlier versions of PCI Express.

Front USB port

A full complement of USB ports supports high-end equipment loaded with rich perif &ehaves, including a USB 3.2 Gen 2 Type-C connector on the front panel that provides data transfer speeds of up to 10 Gbps.

USB 3.2 generaci n 2x2 type C

Wide compatibility with USB guarantees connections to a wide range of rich perif. TUF Gaming Z690-PLUS D4 includes a USB 3.2 Gen 2x2 Type-C port on the rear I/O panel that offers increased bandwidth and transmission speeds &oatecn up to 20 Gbps.

Compatibility with Thunderbolt 4

The TUF GAMING Z690 series is compatible with Thunderbolt 4 through an integrated header. With an additional ASUS ThunderboltEX 4 card certified by Intel TUF GAMING Z690-PLUS D4 tambi &eacorn can enable two-way speeds of up to 40 Gbps on a single cable. In addition, this card has a network connection function for the connection of m &uantil ltiples screens and supports a screen with a resolution of up to 8K. Also, you can provide up to 100 watts of power to request load devices.

PC F &OULDN N &AICAS

The TUF GAMING base plates are ñ ed to be f &aucciles to install and configure the way you want, even for beginner builders. The TUF GAMING Alliance ecosystem facilitates the selection of compatible parts, while the Armory Crate software provides Fan Xpert 4 and hardware information and provides total control of the two-v-noise-noise cancellation, the RGB lighting and the rich perif-configuration configuration. The TUF Gaming platform gives you the arsenal you need to build and optimize your sue ñ s gaming platform, without unnecessary complexity.

TUF GAMING ALLIANCE

Build with trust

TUF GAMING Alliance is a collaboration between ASUS and trusted brands of PC components to ensure compatibility across a wide range of parts, such as PC enclosures, power supplies, CPU coolers, memory kits, and m &aws. With new associations and components that are regularly added, the TUF Gaming Alliance will continue to strengthen &eacercius &uatuentes.

PROTECTION N TUF

SafeSlot and SafeDIMM

PCIe 5.0 is 2 times m &aetuas r &aasicas pido que PCIe 4.0, so Asus adapts the process of manufacturing SMT to the SafeSlot m &aaltius r &aaipido, to ensure the data rates are high. SafeSlot is a reinforced metal sleeve that is added to a PCIe slot to keep a card firmly installed. In the meantime, the ASUS SafeDIMM z &oquires support and protect the memory modules on certain ASUS motherboards, which allows you to insert the dules with speed, require &o-n and confidence.

ESD Guard

The ESD protectors extend the life of the components to the time they avoid giving ñ s to electrost discharges, providing protection for up to +/-10 kV of air discharge and +/-6 kV of contact discharge, far exceeding the respective industrial standards of +/-6 kV and +/-4 kV. The surface-mounted TVS diodes in a dual package on the line help protect your PC from voltage spikes.

TUF LANGuard

TUF LANGuard is a military-grade innovate that integrates advanced coupling technology ñ s and premium capacitors mounted on surface to improve performance, protecting the base plate from lightning and electricity.

Protecci &oatun contra overtensi &oacutin DRAM

The restartable fuses on board prevent ñ from overcurrent and short circuit. This extends beyond the E/S ports to DRAM to safeguard the &util life of your system and attached devices.

Stainless steel rear E/S panel

The TUF GAMING motherboards have a rear stainless steel E/S panel resistant to the corrosi attached with chrome xide &o to provide a life &util til three times m long &aaists as the traditional panels. With this protective function, the TUF GAMING motherboards passed the 72-hour saline fog tests, while other brands only passed the 24-hour tests.

F &AICL CONFIGURE &Oatuis N

M. 2 Q-Latch

The innovative Q-Latch facilitates the installation or extraction of an M. 2 SSD without the need for specific tools. The ñ or uses a simple locking mechanism to secure the M. 2 SSD, eliminating the need for screws perfectly.

Q-LED

The built-in Q-LED problem solution lights provide the PC builders with a prompt prompt to confirm that the key components (CPU, RAM, graphics card, storage devices) work correctly during startup.

Armory Crate

Armory Crate is a new software utility that ñ is used to provide centralized control of compatible products. From a single intuitive interface, Armory Crate allows you to customize the illumination and the RGB effects for each compatible device in your arsenal. The software also provides control of the configuration of an increasing number of ASUS products, including keyboard and rat preferences. Armory Crate even has dedicated product registration and news to help you stay in touch with the ASUS community.

Specifications:

• Details T &eUcics
  • Format: ATX
  • Chipset: Intel Z690
  • Multi-GPU: No
  • Number of PCI Express slots: 5
  • Processor family: PC
  • Supported hard disk drive interfaces: M. 2 PCIe, M. 2. SATA, Serial ATA III
  • N Number of supported processors: 1
  • N DIMM slots: 4

• Processor Socket: Socket 1700
• Processor Family: Intel Core i3-12 ª Gen, Intel Core i5-12 ª Gen, Intel Core i7-12 ª Gen
Intel Core i9-12 ª Gen
• Memory
  • Memory slots
  DIMM
  • Internal memory m &axime: 128 GB
  • Non-ECC: Yes
  • Memory-less memory: Yes
  • Memory channel support: Dual
  • Supported memory types: DDR5-SDRAM
  • Supported memory clock speeds: 4800 MHz, 5000 (OC), 5200 (OC), 5400 (OC), 5600 (OC), 5800 (OC), 6000 (OC)
• V &iudos deo
  • Graphics chipset: Intel
  • M &axime resoluci ó n: 4096 x 2304 Pixels
• Audio
  • Channels of audio output: 7.1
